NC528XD Security Camera
PTZ Pan Tilt and Zoom camera with motorised 2.8-12mm lens enabling more control via the mobile app or set it on a pre-set patrol. Full colour at night. Improvements made to the image sensor -1/1.8 enlarged image sensor enables more light to be gathered. Together with built-in warm-light LEDS this creates an excellent full colour image. Experience technological leaps in AI analytics/intelligent video implemented in this camera such as face and licence plate recognition.
| Camera Type | Bullet |
| Image Sensor | SONY 1/2.8″ Progressive CMOS |
| Maximum Video Resolution Megapixels | 8 |
| Maximum Video Resolution | 3840 x 2160 |
| Lens | 5-50 mm H.FOV 7 to 49° |
| Lens Type | Motorised Zoom |
| Maximum Night IR Distance M | 80 |
| Video Compression | H.265 H.265 H.264 H.264 MJPEG |
| ONVIF depends on firmware version | ONVIF Profile S/G/T 21.12 or greater Http API |
| IP Rating | IP67 |
| Operating Environment | -35ºC to 60ºC 31ºF-140ºF Humidity 20-95 RH |
| Dimensions | Ø242 X 87.4mm |
| Weight Net | 1.427 |
| Accessories | IV2422X IV2490X |
| Power Supply | Power over Ethernet IEEE 802.3af DC12V |
| Power Consumption | <10W |
| Connectors | RJ-45 DC Power Input Analog Video Output Audio In Audio Out Alarm in or out 4 Reset Button |
| Outdoor Use | Yes |
| Vandal Resistant | Yes |
| Frame Rate at Resolution | 25 |
| Day/Night Mode | Auto |
| LED Types | IR |
| Image Enhancement | SMART IR Flip mode Brightness Contrast Saturation Sharpness Hue Mirror Angle Flip Corridor Mode Back Light White Balance Shutter Time Exposure Defog 3D Noise Reduction |
| Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
| Multiple Streams encode format | 3 Streams |
| Audio Streaming | Yes – input connector for external mic |
| Protocols | TCP/IP UDP HTTP HTTPS DHCP FTP RTP/RTSP DNS DDNS NTP PPPOE UPNP SMTP SNMP P2P QR code |
| Intelligent Video IVS | Face Recognition Human&Vehicle Detection Perimeter Intrusion Detection Line Crossing Detection Cross Counting Stationary Object Detection Heat Map Crowd Density Detection Queue Length Detection License Plate Detection Rare Sound Detection |
| Cloud option camera only | Dropbox |
| Software | Device Search/Config Tool Surveillance Client CMS/VMS Mobile app QR code |
| Power Over Ethernet | Yes |
| Ethernet | Ethernet 10/100 Base-T |
| In The Box | Free Software available ivsecurity.com.au/support/software Printed quick user guide installation template mounting screws and plugs |
| Warranty | 3 Year Warranty |
