6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports is a type of layer two commercial switch. It provides 4 10/100 Mbps Ethernet ports and 2 10/100 Mbps uplink ports. The product is equipped with two types of transmission modes (Extend Mode On/Extend Mode Off). It also supports PoE watchdog to avoid manually maintenance and device restart, which can realize the intelligent management and reduce the cost.
- General Information
- Manufacturer
- Zhejiang Dahua Technology Co., Ltd.
- Manufacturer Website Address
- http://www.dahuasecurity.com
- Brand Name
- Dahua
- Product Type
- Ethernet Switch
- Interfaces/Ports
- Total Number of Network Ports
- 4
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 4 x Fast Ethernet Network
- 2 x Fast Ethernet Uplink
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-T
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3x
- Management & Protocols
- Manageable
- No
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 60 W
- Input Voltage
- 53 V DC
- Power Source
- Power Supply
- Redundant Power Supply Supported
- No
- Physical Characteristics
- Form Factor
- Desktop
- Wall Mountable
- Height
- 26 mm
- Width
- 130 mm
- Depth
- 85 mm
- Weight (Approximate)
- 300 g
