Atdec SD-DP-420 Pole Mount for Flat Panel Display - Black

  • Part: 1009717
$213.40

Availability

In Stock

The SD-DP-420 is designed for limited spaces where displays are part of the operational process (such as cafes, shop fronts and other POS environments). The cutting-edge QuickShift™ lever lets the screen be manually moved up and down the pole, without requiring any tools. Viewing angle and screen orientation are also fully adjustable thanks to the ball joint mechanism, finished off with a quick release mechanism to rapidly remove and change screens. Built-in internal cable management ensures a professional finish for maximum display impact. The SD-DP-420 comes with one display attachment head.

  • General Information
    • Manufacturer
    • Atdec Pty Ltd
    • Manufacturer Website Address
    • http://www.atdec.com.au
    • Brand Name
    • Atdec
    • Product Type
    • Pole Mount
  • Warranty
    • Limited Warranty
    • 10 Year
    • Additional Warranty Information
    • Parts and Workmanship
Download user manual (.pdf)

  • Product Information
    • Device Supported
    • Flat Panel Display
    • Number of Displays Supported
    • 1
    • Maximum Load Capacity
    • 12.02 kg
    • Minimum Screen Size Supported
    • 30.5 cm
    • Maximum Screen Size Supported
    • 61 cm (24")
    • Features
    • Swivel
    • Quick Release Mechanism
    • Tilt
    • Pan
    • Cable Management
    • Height Adjustable
    • Yes
  • Physical Characteristics
    • Product Color
    • Black
    • VESA Mount Compatible
    • Yes
    • Mounting Pattern
    • 75 x 75
    • 100 x 100
    • Product Material
    • Aluminium
    • Steel
    • Plastic
  • Miscellaneous
    • Package Contents
      • Donut Pole 420mm
      • 1 x VESA Plate
      • 1 x Quickshift Donut
      • 2 x Cable Ball
      • 1 x Base Casting
      • 2 x Cable Clip
      • 1 x Security Screw
      • 1 x Bolt Through Washer
      • 1 x M8x30mm Screw
      • 1 x 2mm Allen Key
      • 4 x M4x10mm Screws
      • 4 x M4x12mm Screws
      • 4 x M4x16mm Screws
      • 1 x Desk Clamp Bracket
      • 1 x Pressure Plate
      • 1 x M8 Desk Clamp Screw
      • 1 x 5mm Allen Key
    • Additional Information
      • Mounts rear of display 95mm from the wall
      • Features +/- 40° angular adjustment
      • Designed for simple installation
      • Pole length: 420mm
      • Ball joint mechanism allows 20 degrees of display adjustment in any direction from the vertical plane
      • 360 Degree rotation
      • Portrait to landscape rotation
      • Quick Shift lever allows to quickly move and lock the display freely along a pole without using any tools
      • Quick release mechanism for fast display attachment or removal
    • Compatibility

    • LCD

    • Assembly Required
    • Yes
